THS 05T TEM Holder Storage Station

High vacuum automatic pressure maintenance, oil-free and clean

15 independent storage stations with no interference in vacuum retention

2 Automatic pressure maintenance to ensure constant vacuum degree

3 High-vacuum heating and degassing of TEM cryogenic holders

Message consultation

If you want to learn more about product information, make an appointment for sample testing, or consult after-sales service, please leave us a message online, and we will reply to you as soon as we receive your message!

Appointment for trial

If you want to learn more about product information, please leave us a message online to schedule a trial. We will contact you as soon as we receive your message!

Trial product:

Product Introduction Product Specification Download Center

Product Introduction

THS 05T is a high-vacuum TEM holder storage station that uses an oil-free molecular pump system to quickly generate a clean <10-4 Pa-level high vacuum. It is particularly suitable for degassing Dewar cans for cryo-TEM holders and the routine vacuum storage and removal of water vapor for TEM holders.

It is compatible with holders from various brands of TEM, ensuring that the holders remain in a vacuum state for extended periods and reducing the pumping time for TEM sample loading.

Product Specification

Technical Specifications	Parameters
Vacuum Pump	Turbo Pump and Oil-free Diaphragm Pump
Turbo Pump Speed	＞85L/s (N₂)
Diaphragm Pump Speed	＞0.7m³/h
Ultimate Vacuum	＜1E-4Pa
Pump Down Time	＜5min
Vacuum Gauge	Full-range Compound Gauge
Dewar Flask Exhaust Port	Max. 2
Storage Capacity	Max. 5 TEM Sample Holders, Optional Flanges for FEI, JEOL, Hitachi
Operating Method	Touchscreen Control with the Control System Providing Interlock Protection Functions
Weight	~15Kg
Dimensions	320mm * 400mm * 242mm
Power Supply	100-220V AC, 50/60Hz Grounded Three-prong Plug
Power Consumption	＜200W
Warranty	One year
